Viavi 3Z RF Vision Antenna Alignment Tool

• Reduces OPEX costs
• Guarantees field installation and RF Design match
• Maximizes voice quality & data traffic
• Improves data user throughput & KPIs
• Reduces churn
• Keeps your customers happy
• Mechanically Aligned with HD Camera
• Rugged Design & Weather Resistant
• Impact Resistant Display
• 5” Touch Screen LED Display
• Embedded Augmented Reality
• Connects to multiple constellations
• Multiple-frequency technology
• Optional Camera License: allows you to use the built-in camera on the alignment tool

Tool Includes:

• Rugged designed hard-case
• Universal strap clamp
• Water-resistant carrying soft-case bag
• Rubber bumpers for microwave antennas
• AC/DC Power charger & worldwide power adaptors
• 1 Year Manufacturer Warranty

Additional Options:

• Camera License (3Z-RFV-CAML)
• Damage Protection Plan (3Z-RFV-DPP2)

Optional Accessories:

• 3Z Strap Clamp
• 3Z Torque Wrench
• 3Z Air Mount AIR32 Bracket
• 3Z Ground Verification

2 Year Damage Protection Plan

For full details about the 2-year damage protection plan click here.

The 3Z RF Vision Antenna Alignment Tool replaces a compass, GPS, and range finder. This antenna alignment tool is effective and reliable to ensure that installers perform jobs as indicated on RF design specifications. Use the Vision Antenna Alignment Tool for accurate antenna alignment to prevent coverage gaps, network performance gradation, and loss of revenue.

For the first time, an antenna alignment tool can align the antenna and also show you where it is pointing with the built-in HD camera. The camera provides a line of sight image that is mechanically aligned with the tool. The license to use this camera is optional and can be purchased for an additional fee (does not come included with the alignment tool). There is a 30-day free trial of the camera license.

The 3Z RF Vision Antenna Alignment Tool is compatible with all the same accessories (besides the charger) as the 3Z RF Aligner Antenna Alignment Tool.
